Solis S6-EH1P5K-L-PLUS 5.5kVA Hybrid Inverter
The Solis S6-EH1P5K-L-PLUS is a single-phase hybrid inverter designed for residential solar and battery storage systems. Built for energy independence and reliable backup power, it supports high PV input, flexible battery compatibility, and seamless on/off-grid switching for modern home energy systems.
Key features
- Supports PV input up to 160% of rated DC power for improved solar generation.
- Compatible with high-power PV modules with up to 21A input current support.
- Seamless on/off-grid switching in under 10ms for uninterrupted backup power.
- Compatible with lithium-ion and lead-acid batteries from 40V–60V.
- 200% overload capability for 10 seconds in off-grid mode.
- Smart load management for essential backup circuits.
- Generator compatible with automatic control functionality.
- Supports parallel operation of up to 6 units.
- 7-inch LCD display with Bluetooth and app connectivity.
- IP66-rated enclosure for indoor and outdoor installation.
Specs
- Rated output power: 5kW / 5.5kVA.
- Recommended max PV array size: 10kW.
- Max usable PV input power: 8kW.
- MPPT voltage range: 90–435V.
- Max input voltage: 500V.
- Battery voltage range: 40–60V.
- Max charge/discharge power: 5kW.
- Max efficiency: 96.2%.
- Backup switch time: <10ms.
- Cooling: Natural cooling.
- Protection rating: IP66.
- Dimensions: 335 × 560 × 253 mm.
- Weight: 23 kg.
